The cnMatrix platform of switches provides:
- Full Line Rate, non-blocking architecture
- Easy and simple, free cloud (or on premise) management with cnMaestro™
- Zero-touch deployment of switches makes installation easy
- Policy Based Automation eliminates manual and time consuming configuration
- Enhanced Security with automated device profiling and segmentation
- Policy Based Automation eliminates manual configuration during adds, moves and changes of network devices
The cnMatrix series of fully managed switches delivers full Layer 2 and Layer 3 capabilities with enhanced access security. The EX3000 series offers SFP+ (10 Gbps) fiber uplink ports. The EX3000 series also offers dual remove-able power supplies and features up to 60W of PoE per port. These switches come with a 5-Year Limited Lifetime Warranty
Specifications
Features
Forwarding Rate in Mpps (64 Byte Packets): 120
10/100/1000 Ports: 24
2.5 G: Ports: n/a
PoE+ Enabled Ports 802.3af/at/bt (30W): 12
PoE+ Enabled Ports 802.3af/at/bt (60W): 12
Hardware
Max Switch Power (with traffic): 61W
MTBF (Hours): 547.054
Weight: 3.679 Kg (8.11 lbs)
Dimensions: 4.4 x 28 x 44.15 cm (1.73 x 11.02 x 17.38 in)
CPU Speed: 800 MHz
LEDs Per Port: Link/Activity, PoE
PoE+ Power Budget: CRPS dependant
